FEATURES

• Melt setting
  Gently melt delicate foods without burning or scorching
• Hot surface indicator lights
  Know when elements are too hot to touch with a quick glance
• Cooktop "On" indicator light
  A light lets you know when an element is active
• Stainless steel trim
  Complement other stainless steel appliances in the kitchen with this touch of elegance

• Cooktop Surface
  Cooktop Burner Type	4 Ribbon Smooth top
  Element - Left Front	6" 1200W
  Element - Left Rear	8" 2500W Power Boil
  Element - Right Front	8" 2500W Power Boil
  Element - Right Rear	6" 1200W
  Control Location	Right Side
  Control Type	Knob (Infinite switch)
  Cooktop Control Features	Keep-Warm Setting Melt Setting
  Dishwasher Safe Knobs	Yes
  Melt Setting	Yes
  Indicator Lights	4 Hot Surface Red Surface Element "ON"
  Cooktop Type	Radiant Smoothtop
  Fuel Type	Electric
  Filler trim kit	JXTR32B

• APPEARANCE
  Color Appearance	Stainless Steel on Black
  Frame Color / Material	Stainless Steel
  Control Knobs	Stainless Steel Appearance

• WEIGHTS & DIMENSIONS
  Approximate Shipping Weight	43 lb
  Cabinet Width	30 in
  Cooktop Size	30 in
  Cutout Dimensions (Width x Depth) (In.)	28-1/2 x 19-5/8
  Net Weight	37 lb
  Overall Depth	21 in
  Overall Height	4 in
  Overall Width	29 7/8 in

• POWER / RATINGS
  Max. Connected Load (kW) at 208V	5.6
  Max. Connected Load (kW) at 240V	7.4
  Max. Current Draw (Amps) at 208V	26.7
  Max. Current Draw (Amps) at 240V	30.8
  Recommended Circuit Breaker (Amps) at 208V	30
  Recommended Circuit Breaker (Amps) at 240V	40

• CLAIMS & CERTIFICATIONS
  ADA Compliant
  UL
  California Prop 65

• WARRANTY
  Parts Warranty	Limited 1-year entire appliance
  Labor Warranty	Limited 1-year entire appliance
  Warranty Notes	See written warranty for full details
